Platinum Tools 100024C ezEX44 Shielded CAT6 Connector with Internal Ground, 25-Piece

100024C | TS-100024C

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The ezEX-RJ45 Shielded Connector is designed for larger cables and conductors, featuring a patented Hi-Lo stagger load bar that isolates each conductor for improved performance. This simple, one-piece pass-through design eliminates the need for bars or liners, making it easier to verify the wiring sequence before terminating.

Main Features

  • Hi-Lo stagger to isolate each conductor
  • Simple one piece / pass through design, no bars or liners
  • Shielded 5e / 6 / 6A compliant
  • Insulation Diameter (Conductor) - Size range: 0.039” – 0.044” (1.0 –1.12mm)
  • Max Outer Diameter: 0.280” (7.1mm)
  • 50 micron gold plated contacts
  • Solid or Stranded 24-22 AWG
  • TAA, TIA, RoHS, UL & FCC compliant
  • Made in the USA
  • US Patents 9,543,729 B2; 10,116,082 B2; & 10,573,990 B2. Foreign patents.

    • General Information

    Name:Platinum Tools 100024C ezEX44 Shielded CAT6 Connector with Internal Ground, 25-Piece
    Category:Platinum Tools, Data Comm & Networking, Cable Connectors, Network Cable Connectors, ADI Pro Rewards
    UPC Code:849160009962
    Country of Origin:. Country of origin is subject to change.
