Hanwha WRR-P-S204L-128TB Wisenet WAVE NVR with (4) Professional Licenses, 2U RMS, 128TB
WRR-P-S204L-128TB
|SQ-WRRPL128T
Shop All Hanwha Vision
Hanwha WRR-P-S204L-128TB Wisenet WAVE NVR with (4) Professional Licenses, 2U RMS, 128TB
WRR-P-S204L-128TB | SQ-WRRPL128T
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
2U Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 128TB raw (101TB usable after disk formatting and RAID 5 configuration), 470 Mbps recording B/W, 12 HDD Bay (3.5"), Intel Xeon 4410Y, 16GB RAM, Dual 480GB SSD OS drives (RAID 1), Ubuntu 22.04, Support RAID 0/1/5/6 + 8GB NV cache, mDP output, VGA output, 4 x 1GbE NICs, IPMI, Redundant 800W power supplies, Keyboard and mouse included, Rail kit included.
Specifications
ADI Part Number SQ-WRRPL128T Brand Name Hanwha Vision Manufacturer Part Number WRR-P-S204L-128TB Product Name Hanwha Vision WRR-P-S204L-128TB Wave Recording Server (Ubuntu OS) with 128TB Product Type Digital Video Recorder
TAA Compliant Yes
HDMI Yes Number of USB Ports 2 Number of VGA Outputs 2 VGA Yes
ADI Part Number Replaces SQ-S202L1120, SQ-S202L1132 Model Number Replaces WRR-P-S202L1-120TB, WRR-P-S202L1-132TB
Color Black Depth 30.3" Height 3.4" Weight 53.3lb Width 18.9"
Input Voltage 100-240V AC Maximum Power Consumption 800W
Hard Drive Capacity 128TB
Limited Warranty 5-Year
Environmental Certification RoHS, UL Environmentally Friendly Yes Operating System Compatibility Ubuntu 22.04 LTS, Windows 10 IoT Enterprise LTSC, Windows Server 2022
