Hanwha XRN-1620SB1-2TB NVR, 16-Channel 8K NVR with 8-PoE, 2TB Raw, H265, H264, MJPEG
XRN-1620SB1-2TB|SQ-1620SB12T
Hanwha XRN-1620SB1-2TB NVR, 16-Channel 8K NVR with 8-PoE, 2TB Raw, H265, H264, MJPEG
XRN-1620SB1-2TB|SQ-1620SB12T
Hanwha Vision
Hanwha XRN-1620SB1-2TB NVR, 16-Channel 8K NVR with 8-PoE, 2TB Raw, H265, H264, MJPEG
XRN-1620SB1-2TB | SQ-1620SB12T
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Hanwha's XRN-1620SB1 is an 8K NVR (Intel-based), No HDD, 16 channels with 16 PoE/PoE+ ports (PoE Budget 200W), H265,H264, MJPEG compression support. Supports up to 4 fixed internal SATA HDDs (6TB max per HDD), ARB (Automatic Recovery Backup), 140 Mbps recording / up to 32 Mbps playback, Dual stream recording, WiseStream technology, HDMI/VGA dual display, maximum resolution of 32MP recording/display and fisheye dewarping on web and CMS, web UI 2.0 (Plugin-free), AI search (Wisenet AI cameras only), QR Code for mobile app.
Main Features
General Information
Name:Hanwha XRN-1620SB1-2TB NVR, 16-Channel 8K NVR with 8-PoE, 2TB Raw, H265, H264, MJPEG
Category:Hanwha Vision, Video Surveillance, Recording Devices & Servers, Network Video Recorders (NVRs), ADI Pro Rewards
UPC Code:849688017654
Country of Origin:Vietnam. Country of origin is subject to change.
Specifications
ADI Part Number SQ-1620SB12T Bandwidth 140 Mbps Brand Name Hanwha Vision Manufacturer Part Number XRN-1620SB1-2TB Product Type Video Surveillance Station
Connectivity Technology Wired Effective Camera Resolution 32MP Maximum Frame Rate 480fps Number of Channels 16 Video Formats H.264, H.265, MJPEG
TAA Compliant No
Ethernet Yes
ADI Part Number Replaces SQ-XR1610SA2 Model Number Replaces XRN-1610SA-2TB
Depth 17" Width 17"
Maximum Resolution 8160 x 6120
Country of Origin VN
