TP-Link S4500-8GHP2F Omada Pro 8-Port PoE+ Gigabit Smart Switch with 2 SFP Slots

S4500-8GHP2F|FP-S458GHP2F
Shop all TP-Link

TP-Link S4500-8GHP2F Omada Pro 8-Port PoE+ Gigabit Smart Switch with 2 SFP Slots

S4500-8GHP2F|FP-S458GHP2F

Sign In for Dealer Pricing

Become an ADI Customer
TP-Link

TP-Link S4500-8GHP2F Omada Pro 8-Port PoE+ Gigabit Smart Switch with 2 SFP Slots

S4500-8GHP2F | FP-S458GHP2F

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

TP-Link Omada Pro gigabit smart switches provide huge upgrade comparing with previous versions. The switches can be managed by TP-Link Omada Pro SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance. To integrate voice, data and video service on one network, the switch applies rich QoS policies. Administrator can designate the priority of the traffic based on a variety of means including Port Priority, 802.1P Priority and DSCP Priority, to ensure that voice and video are always clear, smooth and jitter free. In conjunction with the Voice VLAN that the switches support, Voice Applications will perform better and smoother. TP-Link Omada Pro smart switches support a complete lineup of L2 features, including IGMP Snooping/ MLD Snooping, 802.1Q/MAC/Protocol VLAN, STP/RSTP/MSTP, Link Aggregation Group (LAG), Port Isolation, Port Mirroring, and 802.3x Flow control function. IGMP Snooping ensures the multicast stream be forwarded intelligently to the appropriate subscribers by the switch, while IGMP Throttling & Filtering restricts each subscriber on a certain level to prevent unauthorized multicast access. Besides, these smart switches also support L2+ features like static routing. It is a simple way to provide segmentation of the network with internal routing through the switch and helps network traffic to be more efficient.

Main Features

  • 8x Gigabit 802.3af/at PoE+ ports and 2x Gigabit SFP slots
  • 150W Total PoE budget with up to 30 W PoE output per port
  • Ideal for the access layer in enterprise networking
  • Centralized cloud management via the web or the Omada app
  • Gigabit Ethernet connections on all ports provide full speed of data transferring
  • L2+ Feature, Static Routing, helps route internal traffic for more efficient use of network resources
  • Advanced security features include IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X and Radius Authentication
  • L2/L3/L4 QoS and IGMP Snooping optimize voice and video applications
  • Comprehensive IPv6 support for management, QoS and ACL
  • Web/CLI managed modes, SNMP, RMON and Dual Image bring abundant management features

    • General Information

    Name:TP-Link S4500-8GHP2F Omada Pro 8-Port PoE+ Gigabit Smart Switch with 2 SFP Slots
    Category:TP-Link, Data Comm & Networking, Hubs, Routers & Switches, Network Switches, ADI Pro Rewards
    UPC Code:840030711923
    Country of Origin:China. Country of origin is subject to change.
