TP-Link AP9670 Omada Pro AX5400 Series Ceiling Mount 4804 Mbps on 5 GHz WiFi 6 Access Point, White
AP9670
|FP-AP9670
Shop All TP-Link
TP-Link AP9670 Omada Pro AX5400 Series Ceiling Mount 4804 Mbps on 5 GHz WiFi 6 Access Point, White
AP9670 | FP-AP9670
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
AP9670, The Omada Pro AX5400 Ceiling Mount WiFi 6 Access Point, provides overall 5378 Mbps speeds with WiFi 6 technologies, such as HE160, 1024 QAM, Long OFDM Symbol, and more. A built-in 2.5G Ethernet port ensures high network throughput. PoE+ supported also provides flexible installations. Integrated into the Omada Software Defined Networking (SDN) solution, AP9670 runs in an efficient management way. Centralized and remote management liberate managers and reduce maintenance costs. High-end business WiFi 6 with speeds up to 5378 Mbps brings 2.6-time speeds than WiFi 5. 1024 QAM ensures 25% more data encoded at one time. Long OFDM Symbol helps 11% faster WiFi speed. HE160 doubles the data at peak transmission times on a single stream. Wi-Fi 6 features such as OFDMA and MU-MIMO handle multiple clients across congested environments like typical office spaces, lodging, and hospitals. Enjoy faster speeds on more devices with less lag. Enjoy faster speeds on more devices with less lag. Customizable WIDS and adaptive WIPS assist in safeguarding critical data and network resources. Intelligent Anomaly Detection and Analysis guarantees 24/7 automatic network anomaly analysis to offer timely optimization advice. AP9670 also provides secure WiFi access along with multiple authentication options (SMS/Voucher/RADIUS) and abundant wireless security technologies, such as WPA3 for worry-free open public networks.
Main Features
- Simultaneous 574 Mbps on 2.4 GHz and 4804 Mbps on 5 GHz totals 5378 Mbps WiFi speeds
- Supports multi-dimensional anomaly detection and analysis for improved IT maintenance efficiency
- Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app
- Double the data at peak transmission times on a single stream with HE160
- Video streams and voice calls are unaffected as users move between locations
- Enables wireless connectivity between access points for extended range and flexible deployment
- Supports both 802.3at PoE+ and DC (adapter included) power supply for flexible installations
- Enterprise-Grade WiFi 6 Speed and Connectivity
- Boosted Network Security and Efficiency
- Easy Management with the Omada App
General Information
Name: TP-Link AP9670 Omada Pro AX5400 Series Ceiling Mount 4804 Mbps on 5 GHz WiFi 6 Access Point, White
Category: TP-Link, Data Comm & Networking, Wireless Access Points
UPC Code: 840030705625
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number FP-AP9670 Brand Name TP-Link Manufacturer TP-LINK Technologies Co., Ltd Manufacturer Part Number AP9670 Product Line Omada Pro Product Model AP9670 Product Name Omada Pro AX5400 Ceiling Mount WiFi 6 Access Point Product Series AX5400 Product Type Wireless Access Point
Beamforming Technology Yes Data Encryption Yes Frequency Band 5.00GHz MIMO Technology MU-MIMO (Multi-User MIMO) Network Band 2.4GHz, 5GHz Power Consumption 17.8000W Wi-Fi Generation Wi-Fi 6 Wireless LAN Standard 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n
Number of Network (RJ-45) Ports 1
Ethernet Technology 2.5 Gbps
Antenna Form Factor Internal Color White Depth 9.60" Height 2.50" Width 9.60"
Mount Type Ceiling Mount, Wall Mount
Encryption Standard WPA2-ENT, WPA2-PSK, WPA3, WPA3-ENT, WPA3-Personal, WPA-ENT, WPA-PSK
Environmentally Friendly Yes Package Contents - Omada Pro AX5400 Ceiling Mount WiFi 6 Access Point
- Power Adapter
- Ceiling/Wall Mounting Kits
- Installation Guide
