Image of 8G-063821

RTI VXP-82 All-In-One Presentation Switcher with Built-In Processor

VXP-82|8G-063821

RTI VXP-82 All-In-One Presentation Switcher with Built-In Processor

VXP-82|8G-063821

Sign In for Dealer Pricing

Become an ADI Customer
Image of 8G-063821
RTI

RTI VXP-82 All-In-One Presentation Switcher with Built-In Processor

VXP-82 | 8G-063821

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The VXP-82 combines a robust control processor with a built-in Audio/Video presentation switcher to deliver a single-box solution for conference rooms, classrooms, and lecture halls. VXP-82 enables control from any RTI touch panels, keypads, remote controls, or mobile apps, while the 8x2 switcher distributes Audio/Video signals over HDMI and HDBaseT simultaneously to up to two rooms. Existing in-room USB web conferencing cameras, microphones and speakers can be connected and switched as well as traditional analog or digital audio and video sources such as computers / laptops, document cameras, media servers and streamers, DVD players, and microphones.

Thus, the VXP-82 is ideal for BYOD settings and social distancing office configurations. KVM control over USB allows for multiple presentation control options using USB keyboards and mice in different spots in the same or secondary room. Additional features include a 4K video scaler and an audio mixer.

Main Features

  • Included in the box:VXP-82, rack ears (2) with screws (6), power cord, Phoenix connectors (3.5 mm, 3 Pins) (2), Phoenix connectors (3.5 mm, 5 Pins) (2), terminal blocks (3 x 4 position, 3x 2 position), RS-232 adapters (2)
  • 8x2 4K All-in-One Scaling Presentation Matrix Switcher.
  • Support for HDCP 2.2 and HDMI 2.0.
  • Built-in scaler supports up to 4K@60Hz 4:4:4 8bit video output.
  • HDBaseT inputs/output using VXP-R/VXP-T Extenders.
  • Cat-5 cable: 4K@60Hz 4:2:0 8bit signal up to 90m/300ft, 1080p@60Hz 4:4:4 8bit signal up to 100m/330ft
  • Cat-6/6a/7 cable: 4K@60Hz 4:2:0 8bit signal up to 100m/330ft, 1080p@60Hz 4:4:4 8bit signal up to 100m/330ft.
  • VXP-R/VXP-T HDBaseT Extenders support PoH (Power over HDBaseT) in addition to Ethernet, IR and RS-232 pass-through.
  • Bi-directional KVM functionality for HDMI or HDBaseT outputs - Ideal for presentation settings.
  • Supports de-embedded audio of HDMI and HDBaseT outputs, set independently to output any mixed result.
  • General Information

    Name:RTI VXP-82 All-In-One Presentation Switcher with Built-In Processor
    Category:RTI, Pro AV, Commercial Video Conferencing, Video Conference Controllers
    UPC Code:810064990557
    Country of Origin:China. Country of origin is subject to change.
