AV Pro Edge AC-MXNET-1G-DV2-W 1G Decoder, Wall Plate, HDMI, USB, MXNet

AC-MXNET-1G-DV2-W | 8A-ACMXGDV2W

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The AVPro Edge AC-MXNET-1G-DV2 is a weatherproof video distribution decoder designed for durability in harsh environments, rated IP68 for protection against water, moisture, dust, salt-air, and corrosion. It features advanced JPEG 2000 encoding and decoding, supporting lossless and lossy compression, 4K/60fps video at high bit depths, and high bitrate multi-channel audio including Dolby Atmos and DTS:X. This decoder includes a built-in OLED data status screen for setup and troubleshooting, supports IR and RS-232 control signal routing, and provides USB and KVM connectivity with expandable ports. The device is optimized for integration with Netgear switches through a dedicated AVPro Edge Profile for seamless operation.

Main Features

  • Weatherproof coating creates a durable, waterproof barrier against water, dust, humidity, salt-air
  • Rated IP68 for protection in outdoor, covered, and direct rain environments
  • Supports JPEG 2000 encoding with wavelet transform for lossless or lossy compression
  • Improved decoded image fidelity with AVPro Edge ASIC and Evolution II series compatibility
  • Supports 4K/60fps 4:4:4 RGB or YCbCr, 10- and 12-bit color depth, and dynamic metadata
  • Supports high bitrate multi-channel audio including Dolby Atmos and DTS:X for IMAX Enhanced
  • Built-in OLED screen displays device setup, troubleshooting info, IP and MAC addresses
  • Receives IR and RS-232 control signals mapped with MXnet Mentor software
  • Includes two USB ports per decoder with USB hub expandability and routing back to Encoder Host
  • Light emission and status LEDs can be controlled or disabled via MXnet Mentor software

    • General Information

    Name:AV Pro Edge AC-MXNET-1G-DV2-W 1G Decoder, Wall Plate, HDMI, USB, MXNet
    Category:AV Pro Edge, Pro AV, Commercial Video Signal Distribution, Pro AV Switches
    UPC Code:810108233107
    Country of Origin:China. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
