Lantronix SISTG1013-211-LRT-B Unmanaged Hardened Gigabit Ethernet Media Converter, 10/100/1000Base-T (RJ-45) 100 m/328' to 1000Base-SX 850nm Multimode (SC)
Lantronix SISTG1013-211-LRT-B Unmanaged Hardened Gigabit Ethernet Media Converter, 10/100/1000Base-T (RJ-45) 100 m/328' to 1000Base-SX 850nm Multimode (SC)
Lantronix SISTG1013-211-LRT-B Unmanaged Hardened Gigabit Ethernet Media Converter, 10/100/1000Base-T (RJ-45) 100 m/328' to 1000Base-SX 850nm Multimode (SC)
SISTG1013-211-LRT-B | P6-SISTG1321
Please sign in to view pricing and availability and to add to cart.
Product Overview
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 1000Base-SX 850nm multimode (SC) [62.5/125 μm: 220 m/722 ft.] [50/125μm: 550 m/1804 ft.] Link Budget: 8.5 dBThe SISTG10xx-211-LRT-B Series is a new generation of unmanaged hardened Gigabit Ethernet media converter. The converter can provide multimode or single mode fiber connections with fixed SC connectors for extending the Ethernet service distance over fiber. The converter also has a SFP version that provides the ultimate flexibility to choose the appropriate SFP module to match your communication and distance needs.
It has redundant input power connections to ensure safe reliable operation in temperatures between -40°C and +75°C. Transition Networks' hardened switches are certified with UL Class 1 Division 2 to operate reliably in hazardous locations such as Oil & Gas, manufacturing, and the chemical industry.
Main Features
General Information
Specifications
ADI Part Number P6-SISTG1321 Brand Name Transition Networks Manufacturer Transition Networks, Inc Manufacturer Part Number SISTG1013-211-LRT-B Maximum Distance 1804.46' Product Model SISTG1013-211-LRT-B Product Name Unmanaged Hardened Gigabit Ethernet Media Converter Product Series SISTG10xx-211-LRT-B Product Type Transceiver/Media Converter
Fiber Optic Mode Multimode Media Type Supported Optical Fiber, Twisted Pair Power Consumption 3.40W
Network (RJ-45) Yes Number of Network (RJ-45) Ports 1 Number of Ports 2 Number of SC Ports 1
Network Technology 10/100/1000Base-T, 1000Base-SX
Ethernet Technology Gigabit Ethernet
ADI Part Number Replaces P6-SISTG1013 Model Number Replaces SISTG1013-111-LRT
Depth 3.9" Height 4.3" Weight 15.52oz Width 1.2"
Power Source Power Supply
Mount Type Rail Mount
Limited Warranty 5-Year
Country of Origin TW Environmental Certification RoHS, WEEE Environmentally Friendly Yes Package Contents - Unmanaged Hardened Gigabit Ethernet Media Converter
- DIN Rail Mounting Brackets
