AV Pro Edge AC-MXNET-1G-EV2 MXnet 1G Evolution II Encoder, 4K / 60fps, 4:4:4

AC-MXNET-1G-EV2 | 8A-ACMXNGEV2

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The AC-MXNET-1G-EV2 is an Evolution II Encoding/Transmitting device from AVPro Edge, designed for AV over IP video distribution within the MXNet Platform. It features a proprietary ASIC with an enhanced software-based video encoding/decoding engine supporting native 4K/60fps 4:4:4 signals, Dolby Atmos and DTS:X multi-channel audio, and HDR formats like Dolby Vision and HDR10+. The device encodes HDMI source signals using an optimized JPEG 2000 codec for minimal latency and efficient compression and supports RS-232, IR, and USB control signal routing. It includes a fan-less design with chip-top heatsinking, an OLED data window for configuration feedback, and USB 2.0 Type-B Host connection for USB/KVM support.

Main Features

  • Supports HDMI 2.0 with 18Gbps bandwidth and HDCP 2.3 compatibility
  • Equipped with Evolution II ASIC with improved encoding engine using optimized JPEG 2000 codec
  • Encodes native 4K/60fps 4:4:4 RGB or YCbCr signals with dynamic metadata including Dolby Vision
  • Supports high bitrate multi-channel audio formats including Dolby Atmos and DTS:X for IMAX Enhanced
  • Includes Genlock frame-syncing for tear-free video wall synchronization
  • Operates with near-zero latency and visually imperceptible delay
  • Supports control signal routing for RS-232, IR, and USB via proprietary MXNet Mentor software
  • USB/KVM support with USB 2.0 Type-B female Host connection and video processing up to 1920x1080p @
  • Features built-in OLED data window displaying device info, IP, and MAC addresses
  • Fan-less design for quiet operation with efficient chip-top heatsinking consuming typically 7W or

    • General Information

    Name:AV Pro Edge AC-MXNET-1G-EV2 MXnet 1G Evolution II Encoder, 4K / 60fps, 4:4:4
    Category:AV Pro Edge, Pro AV, Commercial Video Signal Distribution, Pro AV Switches
    UPC Code:810108230076
    Country of Origin:China. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
    User Manual
