AV Pro Edge AC-MX-88X 8x8 HDMI Matrix Switcher, 4K60, HDR, Advanced EDID

AC-MX-88X | 8A-ACMX88X

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The AVPro Edge AC-MX-88X is an advanced HDMI matrix switcher designed to deliver ultrawide 40 Gbps bandwidth with 8 input and 8 output ports, supporting true 8K and 4K resolutions. It features HDMI 2.1a specification compliance, HDCP 2.3 support, and can handle up to 8K 60 Hz with 4:2:0 sampling or 8K 30 Hz with 4:4:4, plus 4K 120 Hz at 120 fps. The product includes balanced analog audio outputs and supports full HDR formats, including Dolby Vision, HDR10+, and HLG. Control options include IR, RS232, and LAN, with driver support for major control systems such as Crestron and Savant, making it suitable for next-generation AV setups.

Main Features

  • Supports 40 Gbps ultrawide bandwidth with 8K input and output stages
  • Includes HDMI 2.1a specification compliance
  • Supports HDCP 2.3 and earlier versions
  • Up to 8K 60 Hz 4:2:0 and 8K 30 Hz 4:4:4 resolution
  • Supports 4K 120 Hz and 120 fps
  • 8K to 4K and 8K/4K to 1080p downscaling on all outputs
  • Balanced analog audio outputs with 2 CH PCM
  • Full HDR support including HDR 10 and 12 bit
  • Supports Dolby Vision, HDR10+, and HLG
  • Advanced EDID management

    • General Information

    Name:AV Pro Edge AC-MX-88X 8x8 HDMI Matrix Switcher, 4K60, HDR, Advanced EDID
    Category:AV Pro Edge, Residential AV, Pro AV, Residential Video Signal Distribution, Commercial Video Signal Distribution, HDMI Matrix Switches, Pro HDMI Switchers
    UPC Code:810108230120
    Country of Origin:China. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
    User Manual
    Installation Instructions
    Additional Resources
