AV Pro Edge AC-EX70-444-KIT 18Gbps HDBaseT Extender Kit, 4K / 60fps 4:4:4, 70m

AC-EX70-444-KIT | 8A-ACEX74KIT

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The AC-EX70-444-KIT is an advanced HDBaseT extender designed to transmit 4K60 4:4:4 HDR video signals at 18Gbps over a single CAT cable, recommended CAT6a. It uses Invisible Compression Technology (ICT) to deliver nearly lossless high-bandwidth 4K HDR signals without color banding or shifting, maintaining deep color and HDR metadata integrity. Key features include full HDR support (HDR10, HDR10+, HLG), 4K>1080p downscaling, EDID management, 3D support, bi-directional 48 V PoH power, Ethernet pass-through, and bi-directional RS232 transport. The unit supports cascading for ultra-long distances, includes built-in test patterns for troubleshooting, and has ESD protection to 7 KV. This CE certified and RoHS compliant extender is ideal for clean point-to-point HDMI extension, retrofit jobs, and integration in matrix switch systems.

Main Features

  • Supports 4K60 4:4:4 HDR and 18Gbps HDBaseT extender over single CAT cable
  • Includes HDR10, HDR10+ and HLG support with full HDR metadata preservation
  • Employs Invisible Compression Technology (ICT) for virtually lossless high bandwidth transmission
  • Supports 4K>1080p downscaling for mixed system compatibility
  • Features EDID management and emulation for display compatibility
  • Built-in 4K and HD test patterns on transmitter and receiver for troubleshooting
  • Provides Ethernet hub capability with 10/100 Ethernet ports on Tx and Rx
  • Includes L/R audio extraction on Tx and Rx and supports CEC pass-through
  • Bi-directional 48 V PoH power over HDBaseT with single power supply support
  • Supports bi-directional RS232 transport and 3-20 V protected IR transport

    • General Information

    Name:AV Pro Edge AC-EX70-444-KIT 18Gbps HDBaseT Extender Kit, 4K / 60fps 4:4:4, 70m
    Category:AV Pro Edge, Residential AV, Pro AV, Residential Video Signal Distribution, Commercial Video Signal Distribution, HDMI Extenders, Pro HDMI Extenders
    UPC Code:859762007501
    Country of Origin:China. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
    User Manual
    Installation Instructions
    Additional Resources
