Cleerline 6D50125MOM3P SSF Multimode Fiber Cable, 6 Strand, OM3, Plenum Indoor/Outdoor, 50/125, Spool, 1000'

6D50125MOM3P | 4E-6D50MOM3P

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The Cleerline NSF 6 strand distribution cable features OM3 50/125 multimode fiber within a 3.5mm plenum-rated PVC jacket, designed for rapid termination with enhanced strength and bend insensitivity. Its integral 250um soft peel coating eliminates the need for stripping, enhancing glass protection and simplifying installation. The cable offers bend longevity 10,000 times greater than standard fibers, ensuring prolonged performance and safety. Equipped with aramid yarns (Kevlar) for added mechanical strength and fatigue resistance, it maintains ultra-low attenuation even on tight bend radii. The jacket is PVDF UV and moisture-resistant, with sequential footage markings for easy measurement. Suitable for operating temperatures from -20 to +75°C and capable of withstanding tensile loads up to 1000 N during installation, this cable meets plenum rating standards (CL/OFNP/FT6). Compatible with all common connector systems for standard multimode fibers, it is packaged in a 1000ft spool. Explore this advanced fiber solution to enhance your network installation efficiency and durability.

Main Features

  • Simplified fiber termination with integral coating and no stripping required
  • Bend longevity 10,000x longer than normal fibers for extended durability
  • Exceptional bend insensitivity enhances safety during installation
  • Fiber glass protected by 250um soft peel coating and jacket
  • Compatible with standard 50/125 multimode OM3 connectors
  • 3.5mm plenum rated PVC jacket with moisture and UV resistance
  • High mechanical strength with superior fatigue resistance
  • Ultra low attenuation loss on tight bend radius
  • Sequential footage markings and aramid yarn (Kevlar) reinforcement
  • Operates from -20 to +75°C with storage from -40 to +85°C

    • General Information

    Name:Cleerline 6D50125MOM3P SSF Multimode Fiber Cable, 6 Strand, OM3, Plenum Indoor/Outdoor, 50/125, Spool, 1000'
    Category:Cleerline, Wire & Cable, Fiber Optic Cables & Cords, Fiber Optic Cables
    UPC Code:091037209214
    Country of Origin:Taiwan, Province of China. Country of origin is subject to change.
